Product Features
Low pressure, High flux, Antipollution.
Applications
The membrane elements can be used in industrial sewage treatment, recycling of municipal sewage, especially in treatement of contaminated surface water after special treatment for membrane.
Technical Parameters
Model | Permeate Flow GPD (m3/d) | Active Membrane Area ft2 (m2) | Stabilized Salt Rejection | Feed Spacer mil (mm) | Test Conditions |
MW-FR8040-375 | 9400(35.6) | 375(34.9) | 99.5% | 28(0.7) | 225psi/2000ppmNaCl |
MW-FR8040-400 | 9900(37.4) | 400(37.2) | 99.5% | 28(0.7) | 225psi/2000ppmNaCl |
MW-FR8040-440 | 11300(42.7) | 440(38.1) | 99.5% | 28(0.7) | 225psi/2000ppmNaCl |
1. All performance data are collected at 25℃ (77℉), PH7.4 - 7.6 and 15% recovery rate.
2. Permeate flows for single element may vary ± 15%。
Operating Conditions
Maximum Operating Temperature | 45℃(113℉) |
Maximum Operating Pressure | 600psi(41bar) |
Maximum Pressure Drop (single element) | 15psi(1.0bar) |
pH Range for Continuous Operation | 3.0-10.0 |
pH Range for Cleaning | 2.0-12.0 |
Chlorine Tolerance | ＜0.1ppm |
Maximum Feed SDI15 | 5.0 |
Maximum Feed Flux | 17.0m3/h |
Operation Notes
1. Don't produce backpressure in any case.
2. Maximum allowable pressure drop of membrane shell is 50psi (3.4bar).
Scope of Business
1. Technology research and development, Product manufacture.
2. Equipment integration, Complete set of technologies.
3. Water treatment project Design-Build-Operation.
4. To build a complete industrial chain of water treatment business with membrane process and biofilm process as the core technologies.
