Product Features
Low energy consumption, High performance, Stable performance.
Applications
Desalination of brackish water and surface water with salt concentration lower than 8000 ppm.
Technical Parameters
Model | Permeate Flow GPD (m3/d) | Active Membrane Area ft2 (m2) | Stabilized Salt Rejection | Feed Spacer mil (mm) | Test Conditions |
MW-BW8040-375 | 11260(42.6) | 375(34.9) | 99.5% | 28(0.7) | 225psi/2000ppmNaCl |
MW-BW8040-400 | 11500(43.5) | 400(37.2) | 99.5% | 28(0.7) | 225psi/2000ppmNaCl |
MW-BW8040-440 | 12000(45.4) | 440(38.1) | 99.5% | 28(0.7) | 225psi/2000ppmNaCl |
MW- BW4040 | 2050(7.7) | 85(7.9) | 99.5% | 28(0.7) | 225psi/2000ppmNaCl |
1.All performance data are collected at 25℃ (77℉), PH7.4 - 7.6 and 15% recovery rate.
2.Permeate flows for single element may vary ± 15%.
Operating Conditions
Maximum Operating Temperature | 45℃(113℉) |
Maximum Operating Pressure | 600psi(41bar) |
Maximum Pressure Drop (single | 15psi(1.0bar) |
pH Range for Continuous Operation | 3.0-10.0 |
pH Range for Cleaning | 2.0-12.0 |
Chlorine Tolerance | ＜0.1ppm |
Maximum Feed SDI15 | 5.0 |
Maximum Feed Flux(BW-8040) | 17.0m3/h |
Maximum Feed Flux(BW-4040) | 3.7m3/h |
