Company Profile
Zhongfu membranes & water technology CO., LTD is affiliated to China Composites Group Co., Ltd., the Sub-company of China National Building Materials Co., Ltd. (CNBM). The company locats in lianyungang city, jiangsu province, was established in 2011. It has more than 150 employees, of which engineering staff is more than 60. Zhongfu membranes & water technology CO., LTD is a new high-tech enterprise with development, design, production, service for products and equipments of membranes and membrane elements, takes reverse osmosis membranes, nanofiltration membranes and membrane elements as main product, take membrane water treatment equipments as the core under the support of urban water supply and drainage network, seawater desalinization, sewage treatment project.
Product Features
High removal rate of organic matter, High rejection, High flux, Water Softening effectively.
Technical Parameters
Model | Permeate Flow GPD (m3/d) | Active Membrane Area ft2 (m2) | Stabilized Salt Rejection | Feed Spacer mil (mm) | Test Conditions |
MW-NF8040-375 | 10500(39.7) | 375(34.9) | 97% | 28(0.7) | 75psi/2000ppmMgSO4 |
11000(41.6) | 375(34.9) | 30-50% | 28(0.7) | 75psi/1000ppmNaCl | |
MW-NF8040-400 | 12000(45.4) | 400(37.2) | 97% | 28(0.7) | 75psi/2000ppmMgSO4 |
13000(49.2) | 400(37.2) | 30-50% | 28(0.7) | 75psi/1000ppmNaCl |
1.All performance data are collected at 25℃ (77℉), PH7.4 - 7.6 and 15% recovery rate.
2.Permeate flows for single element may vary ± 15%.
Element Dimension:
Model | Dimensions - Inches (mm) | ||
A | B | C | |
MW-NF8040-375 | 40.0(1016) | 1.12 (28.5) | 7.9(201) |
MW-NF8040-400 | 40.0(1016) | 1.12 (28.5) | 7.9(201) |
Operation Notes
Before installation please don't unpack the membrane elements, store in a dry and ventilated place away from light with temperature between 10 and 35℃. Elements should be handled with care when in transit.
